2026 OpenClaw Gateway Prometheus Metrics & Grafana Dashboards: Enable /metrics Scraping, Alert Thresholds & False-Positive Triage on Remote Physical Mac 7×24 (Copy-Paste Scrape, Panel Queries + FAQ)

2. Pain points

1. Constraint: bind address vs. where Prometheus runs. If the gateway listens only on 127.0.0.1 but Prometheus is in a container or on a separate observability host, scrapes fail—up=0—while local curl on the Mac still works.
2. Hidden cost: high-cardinality labels & aggressive scrape_interval. Putting raw paths or API-key fragments into labels explodes TSDB cardinality; 1s scrapes over Wi‑Fi or tunnels amplify jitter into Grafana “hair” charts.
3. Stability & false positives: macOS power saving & deploy windows. Display sleep, disk sleep, or a hot reload can spike p95 briefly; alerts with for: 0s will wake on-call for noise.

3. Scraping & alerts: decision matrix

Before go-live, align on “who scrapes from which network namespace” and whether alerts should respect business hours.

4. Seven-step runbook (remote physical Mac)

1. Confirm endpoint & bind. Enable metrics in gateway config; check metrics_path (often /metrics) and listen IP. For remote scrapes, avoid 127.0.0.1-only unless the scraper shares that namespace.
2. Local smoke test. curl -sS http://127.0.0.1:<port>/metrics | head -n 40 and verify HELP/TYPE lines for HTTP and process metrics.
3. Choose scraper placement. Single-node PoC: co-located Prometheus. Many nodes: vmagent remote-write or centralized Prometheus with firewall allowlists.
4. Author scrape configs (below). Use scrape_interval: 15s–30s, sensible scrape_timeout, stable instance relabeling.
5. Wire Grafana. Add the Prometheus datasource; build panels for global RPS, p95, 5xx ratio, up, and scrape duration.
6. Define alerts & routes. Use different for for error ratios vs. raw up; use Alertmanager silences or CI-driven maintenance flags during deploys.
7. Align macOS 7×24 settings. Prefer wired Ethernet, disable disk sleep, fix timezone & NTP. Separate permission and SecretsRef issues from metrics: when the scrape looks healthy but the app returns 500, check application logs before blaming Prometheus.

5. Copy-paste scrape, PromQL & alerts

5.1 Prometheus scrape_configs snippet

Replace targets and port with your gateway listen address. Behind a reverse proxy, allow /metrics through and disable caching for that path.

scrape_configs:
  - job_name: openclaw-gateway
    scrape_interval: 15s
    scrape_timeout: 10s
    metrics_path: /metrics
    static_configs:
      - targets:
          - '127.0.0.1:18789'
        labels:
          env: prod
          role: gateway
    # relabel_configs:
    #   - source_labels: [__address__]
    #     target_label: instance

5.2 Grafana panel queries (replace metric names to match your host)

• Requests per second (RPS): sum(rate(http_requests_total{job="openclaw-gateway"}[5m]))
• p95 latency (histogram): histogram_quantile(0.95, sum(rate(http_request_duration_seconds_bucket{job="openclaw-gateway"}[5m])) by (le))
• 5xx ratio (example): sum(rate(http_requests_total{job="openclaw-gateway",status=~"5.."}[5m])) / sum(rate(http_requests_total{job="openclaw-gateway"}[5m]))
• Scrape health: up{job="openclaw-gateway"} and scrape_duration_seconds{job="openclaw-gateway"}

5.3 Alert rules (Prometheus rule_files)

groups:
  - name: openclaw_gateway
    rules:
      - alert: GatewayScrapeDown
        expr: up{job="openclaw-gateway"} == 0
        for: 2m
        labels:
          severity: critical
        annotations:
          summary: "OpenClaw metrics endpoint not reachable"
      - alert: GatewayHigh5xxRatio
        expr: sum(rate(http_requests_total{job="openclaw-gateway",status=~"5.."}[5m])) / sum(rate(http_requests_total{job="openclaw-gateway"}[5m])) > 0.05
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "5xx ratio > 5% (adjust labels to your schema)"

If your metrics use code or a custom outcome label instead of status, rewrite the selectors accordingly—validate non-empty vectors in Grafana Explore before promoting to alerts.

6. Typical false-positive triage

7. Cite-ready thresholds

• scrape_interval: 15s in production (do not go faster than your gateway’s own tail latency without reason); 30s on intercontinental links.
• scrape_timeout: keep ≤ ~2/3 of scrape_interval; start at 10s for tunneled paths.
• Alert for: availability-style rules from 2m; ratio rules from 5m, then tighten after aligning with SLO burn rates.

8. FAQ

9. Wrap-up & node choice

Once OpenClaw Gateway HTTP and process metrics live in Prometheus and Grafana, failures on 24/7 physical nodes shift from “SSH and guess” to checking whether up, error rates, and p95 move together. The recurring themes are matching bind addresses with scraper network paths, using for on alerts, and stripping macOS power-saving and deploy windows out of SLO noise.
